Automatic Welding Machine Wire Mesh Stud Welding Machine laser
welding machine for metal
Introduction
It emits laser by the fiber transmission, welding for workpiece
with multi-point or multi-surface.Its laser beam is high quality,
welding spot uniform and small,easy to install and move,etc.The
fiber transmission can effectively suppress the focal motion of the
focused beam caused by the beam mode changes that cause by the
thermal lens effect of the laser source.
It effectively improves the quality and stability of welding.The
structure design and solid metal outermost cover ensure that this
laser system can be used in an online industrial production. And
has a better protection for the impact, dust, vibration and
temperature widely changes.
The laser source consist of the lens, laser rods and other
components.
Feature
Welding beam energy distribution , have the best spot for welding
needs
Applicable to all kinds of complex welding , welding of various
devices
Equipped with 5m fiber cable, flexible to weld variety of
work-piece
CCD camera surveillance system , allowing easy observation and
precise positioning
Customized automation tools , can meet mass production of products
Output energy is more accurate and more stable
Application
Sanitary industry: pipe joints, adjustable fittings, tees, valves
Battery industry: lithium-ion battery, battery, electrode laser
welding
Glasses Industry: stainless steel, titanium alloy materials glasses
of snap, and frame position precision welding
Hardware industry: impeller, water bottle, water cupwine pot ,
stainless steel Bowl, sensors, diodes, aluminum, cell phone
batteries, door knobs stirrer, shelves and other complex stamping,
welding of cast parts.
Parameter
| Model No. | CY-WD500 |
| Laser Power | 500W |
| Laser Source | Nd: YAG pumped by xenon lamp |
| Pulse Width | 0.2~20ms |
| Pulse Frequency | 0~100Hz |
| Laser Welding Depth | ≤1mm |
| Adjusting rang of light spot | 0.1-3.0mm |
| Cooling System | 3HP industrial water chiller |
| Power Supply | 380V±5%, 50Hz |
| Power Consumption | 18KW |
| Single Pulse Energy | 120J |
| Observing System | CCD and LCD display, with red pointer |
| Control System | Industrial PC with CNC 2000 software |
| 3-axis Travel Distance | X=300mm,Y=200mm,Z=300mm (all electrical, precision ±0.02mm) |
| Data Memorization | 100 groups |
| Illumination | LED circle lamps |
| Language Display | English & Chinese |
| Shield Gas Supply | 1line, argon |
| Running Environment | Tem 5°C-30°C, Hum 5%-85% |
